Owners and friends who have experience in decoration know that water and electricity decoration is the top priority in house decoration. As a hidden project, hydropower renovation is very important, and every construction step is very important.
1. Hydropower is horizontal and vertical
"Horizontal, horizontal and vertical" has always been the principle of hydropower laying that Xiaobian has repeatedly emphasized. Regardless of aesthetics or industry management, the distance between the switch and the ground is generally about 140 cm, and the height between the socket and the ground is 30 cm.
Line pipe laying, the line pipe laying must determine the reserved position of the water pipe, otherwise there will be problems in the later stage, the maintenance cannot find the position, and more serious decoration accidents will be found in the maintenance process!
2. Water and electricity pipes
We all know that there are two types of electric conduits: strong electric and weak electric. The key points are: the strong electric conduits of some brands on the market are red, and the blue conduits are blue. It is recommended to choose this type. Eight fall, the red and blue lines are easy to distinguish, and it is also easy to distinguish and repair in the later stage. Similarly, water pipes are divided into hot and cold water pipes, as well as single and double layers.
3, tin foil isolation
In order to avoid mutual interference between the currents between strong and weak currents, causing circuit damage and causing potential safety hazards, during construction, the strong electrical conduits and the weak electrical conduits (mainly at the intersections of some turns) must be separated by tin foil. Reduce interference between currents.
4. The regional trend of line pipes
During decoration, the line laying is generally divided into regional line pipe direction, which means that the line pipe will come out of the main electrical box, will first be concentrated in the corridor, and then be diverted to various spaces of the house. The reason for this is to facilitate future maintenance. Because even if the circuit in the house fails and damages in the future, it will be concentrated in the corridor, which can reduce the damage to the floors of other spaces caused by circuit maintenance.
5. Toilet shift
The master uses a 120 flat tube shifter, and the floor drain is moved to the right rear side of the toilet to prevent the floor drain from being stepped on by the foot of the toilet in the future. It is convenient to use the smart toilet cover in the future, so a socket is reserved on the right side of the toilet, and the left side is the water inlet pipe of the toilet.
6. The water outlet is hot on the left and cold on the right
Most of the water outlets are hot on the left and cold on the right. Don’t do it the other way around, otherwise it will be very uncomfortable to use! Under normal circumstances, the distance between the hot and cold water pipes is 15cm! If the water head is not level, ensure the middle to middle size of the outlet elbow and the distance from the wall.
7. Height standard of sockets in different positions
The location of the socket in the living room, the height of the socket of the general TV cabinet is about 35 cm, of course, this depends on the height of the TV cabinet in your home! When arranging the socket in the bedroom, it is recommended that the height be more than 1 meter. Also, remember not to use the original line of the rough house, because if you use the previous line, if there is a problem later, it will be very troublesome to maintain!
8. The ground line is two points and one line
Some plumbers always lay the wires horizontally and vertically, saying that this can better refer to the circuit layout during subsequent decoration, and will not damage the existing wires and cause unnecessary trouble. But you must understand that in fact, your home decoration does not need to nail nails or smash holes on the ground, so the laying of ground wires is recommended to be two points and one line, which saves time and money.
9. Install air switch and leakage circuit breaker
These safety-guaranteed devices are very important! Some developers are also equipped with air switches when handing over the house, but there should be no guarantee of quality. We'd better purchase and install it separately. It is also good for us to choose safety certification. Safe and responsible!
10. Pay attention to loop design
The power of air conditioners, water heaters, ovens, and other electrical appliances in the home is relatively large. If you use the air switch at the same time, it will trip. If you often encounter this situation, it is also an annoying thing. The best way is when wiring Select wire rules and design special circuits for high-power electrical appliances according to power!
11. Horizontal grooves cannot be opened on the wall
If you choose to make grooves on the wall for waterway engineering, you need to waterproof the inner wall of the groove, and then apply the waterproof material before laying the pipeline! And pay attention to whether it is a waterway or a circuit, the wall can only be grooved vertically, never horizontal grooves. !
12. It is best to use a three-way switch in the master bedroom
Many people say that it is good to have a double-control switch in the bedroom. In fact, it is best to use a three-way switch for the master bedroom, two ends of the bed and the door; one socket on each side of the bedside table, table lamps, etc. are very convenient; mobile phone charging is not recommended at the bedside if it is in the bedroom If there is a TV or a bay window, you can consider where to replace the ordinary socket with a USB interface; the size of the bed must be determined in advance, and the socket will be useless if it is blocked.
