Architectural Applications
Geometric wood wall panels represent a convergence of computational design and organic materiality. These engineered surfaces employ non-repeating tessellation patterns derived from Voronoi diagrams and Delaunay triangulation algorithms, creating visual rhythm through:
Angular Variance: 30°-150° interlocking joints
Texture Modulation: 0.8-3mm relief depths
Light Interaction: Shadow gap systems (5-15mm)
Material Specifications
| Wood Species | Janka Hardness | Grain Structure | Optimal Use Cases |
|---|---|---|---|
| White Ash | 1,320 lbf | Open porous, wavy | High-traffic commercial walls |
| Terminalia | 1,740 lbf | Interlocked, coarse | Humidity-resistant installations |
| Radiata Pine | 710 lbf | Even, straight | Cost-effective geometric accents |
| Poplar | 540 lbf | Diffuse porous | Painted finish applications |
*All woods FSC-certified with ≤8% MC (EN 13183-1)*
Technical Performance
Structural Integration
Panel dimensions: 1220×2440×18mm (±0.3mm tolerance)
Concealed fastening: Aluminum T-track system with thermal break
Expansion compensation: 2mm/m climate joints
Environmental Resilience
Dimensional stability: ≤0.6% movement at 30-65% RH (ASTM D1037)
Fire rating: Class B-s1,d0 (EN 13501)
Acoustic enhancement: 0.35-0.55 αw (reverberation control)
Fabrication Methodology
Digital Workflow
3D surface scanning → Point cloud processing → CNC path generation
Grain direction optimization via finite element analysis
Precision Milling
5-axis CNC machining at 18,000 RPM
±0.15mm cutting accuracy (ISO 2768-m)
Finishing Protocol
Water-based UV cure: 3-layer crosslinked polymer
Microbevel edge treatment (0.5mm radius)
Sustainable Implementation
Carbon Sequestration: 12.3 kg CO₂/m² stored in panels
Zero-Waste Production: 98% material utilization through nesting optimization
Circular Design: Demountable systems for future reconfiguration
Design Integration Guidelines
Substrate Preparation
Maximum substrate deviation: 2mm/2m
Vapor barrier requirement: >1.0 perm rating
Lighting Considerations
Recommended illumination: 200-300 lux at 3000K CCT
Grazing light angles: 15°-35° from surface
